Type K Thermocouple Wire
Chromel-alumel wire that carries the signal from your type K thermocouples, the most used in industry, to the control instrument.
- Up to 1260 °C / 2300 °F Measuring range
- Yellow and red ANSI color code
- 20 AWG Standard gauge
- Spools of 25 to 500 m Supplied as
- Direct manufacturer
- ISO 9001:2015
- Reply in under 2 h
Who supplies this wire
From the same people who build your heater
Omega Heaters de México has spent over 25 years building industrial electric heating elements and instrumentation for industry across northern Mexico. Type K wire ships from its warehouse in Guadalupe, Nuevo León, cut to whatever length you ask for.
- Direct manufacturer Our own plant in Guadalupe, Nuevo León, Mexico. We are not distributors.
- Over 25 years Building industrial electric heating elements for industry across northern Mexico.
- ISO 9001:2015 Certified processes and raw materials, audited, with a warranty against manufacturing defects.
- The right alloy, not an imitation Chromel and alumel, with the ANSI yellow-and-red color code and whatever IEC code your standard calls for.
- By the spool or by the meter Spools of 25, 50, 100 and 500 meters, or the exact run you are short.
- Thermocouple grade and extension grade We tell you which one you need depending on whether you will measure with it or only carry the signal.
- Sensor from the same supplier Thermocouples, thermowells and the control panel come out of the same plant, so the loop arrives complete.
Technical data
Specifications
- Composition
- Positive chromel (Ni-Cr) · negative alumel (Ni-Al)
- Measuring range
- Up to 1260 °C / 2300 °F
- ANSI color code
- Positive yellow · negative red
- IEC color code
- Positive black · negative white · green jacket
- Tolerance classes
- Standard and special, the latter tighter
- Gauges
- 20 to 16 AWG
- Shielded version
- With braid, for runs alongside VFDs or power cables
- Supplied as
- Spools of 25, 50, 100 and 500 meters, or by the meter
Aplicaciones
- Industrial furnaces, muffle furnaces and high-temperature heat treatment.
- Extrusoras e inyectoras de plástico.
- Temperature control panels industrial.
- Ambientes con alta interferencia electromagnética: turbinas, transformadores, sistemas ferroviarios (versión blindada).
- Replacing instrumentation wiring damaged by heat or wear.
Qué ganas
- The widest temperature range among base metal thermocouples: up to 1260 °C / 2300 °F depending on the gauge and the protection used.
- Good corrosion resistance thanks to the high nickel content of both alloys.
- Measurement accuracy: because it uses the same alloy as the sensor, it adds no error from a junction of dissimilar metals.
- A shielded option to protect the signal where there are motors, variable frequency drives or transformers nearby.
EMERGENCY SUPPORT
Not sure which gauge to order? Send a photo on WhatsApp.
No part number needed. From a photo of the wire you are replacing and the distance from the sensor to the panel, an engineer will tell you right away the gauge and the insulation you need — chromel-alumel, type K, shielded if there is interference — and how many meters.
1
Tell us the gauge and the length
la distancia que necesitas cubrir entre el termopar y el instrumento.
2
Tell us the conditions along the run
temperatura ambiente, interferencia eléctrica cercana, humedad o exposición química.
3
Te recomendamos el aislamiento correcto
PVC, fibra de vidrio o Teflón según tu ambiente. la muéstrala configuración
Te contesta un ingeniero de aplicaciones
Lun–Vie 9:00–17:00 · respuesta < 2 h
CATÁLOGO • MÁS MODELOS
¿Buscas otro calibre o presentación?
Browse all available thermocouple wire options.
Ver todos los modelos
CATÁLOGO
Desliza para ver más →
Frequently asked questions
What we get asked most
Why is type K the most used in industry?
Because it covers the widest temperature range among the economical thermocouples, up to 1260 °C / 2300 °F, and its high nickel content gives it good corrosion resistance compared with other types. That makes it the default choice in furnaces, heat treatment and industrial processes generally.
What is the difference between thermocouple grade and extension grade wire?
Both use the same chromel-alumel alloy. Thermocouple grade meets a tighter error tolerance and is used to make the measuring tip of the sensor. Extension grade costs less and is only used to carry the signal — not to measure directly.
When do I need the shielded version?
When the wire runs near large motors, transformers, variable frequency drives or turbines. That equipment generates electromagnetic interference that can distort the thermocouple's low-voltage signal; the aluminum shield with a drain wire protects the signal from that noise.
Can I use type K in atmospheres containing sulfur?
It is not advisable. Sulfur attacks the nickel alloys in type K and can damage both the sensor and the wire. If your process has sulfur present, tell us and we will recommend a protective thermowell or a more suitable thermocouple type.
How far can I run the wire without losing accuracy?
It depends on the gauge: a heavier gauge means lower resistance and less signal loss over long distances. Tell us the distance you need to cover and we will recommend the right gauge.
What is the lead time?
3 to 4 business days on standard 100 and 200 meter spools. Special lengths, gauges or the shielded version to order — ask about availability over WhatsApp.
What else is this wire called?
It also goes by type K extension wire, compensating cable, thermocouple wire and thermocouple lead wire. Same product, different names depending on the plant.
What color is type K?
In the ANSI code it is yellow on the positive leg — the chromel — and red on the negative — the alumel. In the IEC code it is black positive, white negative and a green jacket. Red on the negative is shared by J and K in ANSI, so it is the color of the positive leg that tells you which type you have. If yours follows IEC, send a photo and we will confirm it.
Do you sell by the meter or only by the spool?
By the spool and also by the meter: for a single replacement you do not have to buy a whole spool. We carry different gauges and insulations — PVC, fiberglass and Teflon — and we can make up a finished length with a connector if you ask for it that way.
Can you just tell me what to order? I don't know any of this.
Yes. Send us a photo of the wire you are replacing, another of your controller, and the distance from the sensor to the panel. With that we will tell you the type, the gauge, the insulation, how many meters you need, and whether the shielded version is worth it. An engineer answers.
